LS Alternator Bracket (Low Mount, G8 Idler) - LS1 Camaro Spacing

LS Low Mount Drivers Side Alternator Bracket with G8/SS/Caprice Idler Pulley Location for LS1 Camaro Spacing

*if using an iron engine block, it will only have one of the three holes to mount the alternator.  To get the minimum two holes, use our drill template, then drill & M10 tap.  or use our strongly recommended bracket and template kit to get the third bracket mounting hole.

Product Details:

• Compatible with all LS truck/G8/SS/Caprice bolt pattern (5.46") alternators
• Compatible with 1998-2002 Camaro LS1 (2004-06 GTO)
  harmonic balancer
• This kit is a recreation of the G8 style low-mount alternator bracket with a more compact idler location, and utilized on the common "LS1 Camaro" spacing
• Uses the factory (L77 L76) SS, G8, Caprice idler pulley location
• Made in Wichita, Kansas from 6061-T6 USA produced billet aluminum
• Includes: alternator bracket, rear bracket, idler pulley, instructions, and mounting hardware

Helpful Links & Guides

• Belt length chart
• Replacement bolt and spacer kit
• Instructions
• Optional alternator wire harness extension: 4 pin connector or 2 pin
