LS Alternator / Power Steering Pump Bracket Kit (for LS1 Water Pump) Turnbuckle

LS Alternator and LS1 Camaro Power Steering Pump Bracket Kit - for LS1 Camaro Water Pump

Product Details:

• ONLY compatible with LS1 Camaro water pump
• Compatible with 1999-13 LS Truck (& 2010-15 Camaro) harmonic balancer

• Compatible with 1998-02 LS1 Camaro power steering pump and pulley (or billet 2pc pulley)

• Compatible with 105 amp case alternator will NOT fit large case or Corvette/CTSV 2010-15 Camaro bolt pattern alternators.
• Compatible with all LS series engines
• Made in Wichita, Kansas from 6061-T6, USA produced billet aluminum

• Optional LS throttle body rotation adapter needed when using with LS3 Camaro intake manifold and throttle body

Helpful Links & Guides

• Torque specs: Flange bolts (M10 = 37 lb-ft, M8 = 18 lb-ft), FHSC bolts (M10 = 31 lb-ft)
• Belt length chart
• Replacement tensioner
• Optional alternator wire harness extension: 4 pin connector or 2 pin
• Optional high amp alternators that uses 105amp case: 165a PowerMaster, 170a Mechman, 240a Mechman
• Replacement bolt and spacer kit for alternator or power steering bracket
• Instructions
