LS OEM Fox Body A/C Compressor Alternator Power Steering Bracket Swap Mustang AC

LS to Fox Body Power Steering Alternator and A/C Compressor Bracket Kit

This kit is designed specifically for an LS swapped Fox Body Mustang (1979-1993)(Third Generation)

• Compatible with a 1982-1993 Mustang Factory A/C Compressor - 6P148A Compressor
• Compatible with a 1990-2004 Mustang factory power steering pump and pulley (F1ZZ3A674BBRM & D9ZC3D673A3A)
• Compatible with all LS truck bolt pattern alternators (Except Corvette, CTS-V or 10-15 Camaro)

• Compatible with a 1982-1993 Mustang Factory A/C Compressor - 6P148A (Ford "factory" installed) Compressor
• (Does Not Work with Ford "dealer" (Installed A/C Compressor - SD709 Compressor)
• Compatible with 99-13 GM Truck/SUV and 10-15 Camaro harmonic balancer

• Includes: bracket, idler pulleys, tensioner, and mounting hardware
• Made in Wichita, Kansas from 6061-T6 USA produced billet aluminum

*if using an iron engine block, it will only have one of the three holes to mount the alternator.  To get the minimum two holes, use our drill template, then drill & M10 tap.  To get the optional third hole you can use our support bracket

Helpful Links & Guides

• Belt length chart
• Replacement smooth pulley
• Billet smooth pulley

• Replacement bolt and spacer kit
• Optional alternator wire harness extension: 4 pin connector or 2 pin
• Replacement bolt and spacer kit for alternator or power steering bracket
• Instructions
