LS 3-Bolt Intake to LS/LT1 4-Bolt Throttle Body Adapter

LS 3 Bolt Intake to LS/LT1 4 Bolt Throttle Body Adapter

Product Details:

*NOT compatible with mechanical throttle body intake

• 75mm through hole, tapers to 92mm
• Compatible with 75-92mm throttle bodies LS 4-bolt (except LS4) and Gen V: LT1, LT2, LT4, L86, L87, L8B, L8P, L8T
• Compatible with 75-103mm intake manifold that use to have LS 3-bolt electronic DBW throttle body (2003+ (L33, L59, LM4, LM7, LQ4, LQ9, LR4) (LS1, LS6 Corvette 1997-04))

• Plate has 4x M6-1.0mm threaded holes
• Made in Wichita, Kansas, from 1/2" thick 6061-T6 USA produced billet aluminum
• Includes: adapter, oring, and mounting bolts


Helpful Links

• Torque bolts to 106 lb-in
• Replacement -240 oring
